IP67 Waterproof Micro USB Wire Harness Custom Molded USB Cable Assembly
Welcome Calls：
Unitech Energy System Limited was founded in 2014. The factory covers about 110,000㎡ . and We have more than 270 employees, including over 37 engineering technicians. We mainly produce custom wire harness and battery pack accessories(which include: Nickel Strip Tabs; Case Enclosures; Battery Spacer Holders; Shrinkable Sleeve and Battery Insulation Paper etc). Our products are widely used in Medical Electronic Appliances, Military Electronics, Aerospace Electrical A
Product Description
IP67 Waterproof Micro USB Wire Harness Custom Molded USB Cable Assembly
Product Details
| Cable specification |
0.15mm2~0.2mm2/ 26~24 AWG |
||
| Diameter range | Φ5.5mm~Φ7mm | ||
| Contact diameter × number | 9/4 | ||
| Rated Current (A) | 1.5A | ||
| Withstanding Voltage (AC.V) 1 minute | 1000V,2.0-500V,3.0-100V | ||
| Insulation resistance | >500MΩ | ||
| Protection level | IP67 | ||
| Durability | ≥500times | ||
| Working temperature | -40℃~80℃ | ||
| Connecting mode | Quickly bayonet connect | ||
| MATERIALS | |||
| Housing&insulation parts | high-porformance engineering plastics | ||
| Hardware | zinc alloy(pearl hard chrome) | ||
| copper pins | copper Shell | ||
| waterproof cover | Silica gel | ||
| Flammability rating | UL94-V0 | ||
IP67 Waterproof Micro USB Wire Harness Custom Molded USB Cable Assembly
IP67 Waterproof Micro USB Wire Harness Custom Molded USB Cable Assembly
IP67 Waterproof Micro USB Wire Harness Custom Molded USB Cable Assembly
