GX12 M12 4 Pin Male to Female Wire Harness Custom Waterproof Extension Cable
Welcome Calls：
Unitech Energy System Limited was founded in 2014. The factory covers about 110,000㎡ . and We have more than 270 employees, including over 37 engineering technicians. We mainly produce custom wire harness and battery pack accessories(which include: Nickel Strip Tabs; Case Enclosures; Battery Spacer Holders; Shrinkable Sleeve and Battery Insulation Paper etc). Our products are widely used in Medical Electronic Appliances, Military Electronics, Aerospace Electrical A
GX12 M12 4 Pin Male to Female Wire Harness Custom Waterproof Extension Cable
Product Details:
| CONDUCTOR | (AWG) SPECIFICATION | 26 |
| MATERIAL | bare copper | |
| CONFIGURATION | 10/0.120BC±0.007mm | |
| INSULATION | AVG. THICK | 0.26mm |
| OVER DIAMETER | 1.00±0.05mm | |
| MATERIAL | PVC | |
| COLOR | Red/green/black/yellow(wrap shield) | |
| SHILED | MATERIAL | bare copper |
| CONFIGURATION | 30/0.10±0.005 | |
| JACKET | AVG. THICK | 1.25mm |
| OVER DIAMETER | 5.0±0.1mm | |
| MATERIAL | PVC | |
| COLOR | black | |
|
ELECTRICAL CAPABILITY |
RATED TEMPERATURE | -10℃~80℃ |
| RATED VOLTAGE | 30V | |
| COND. RESISTANCE | 159.15Ω/KM·20℃ | |
| INSU. RESISTANCE | 5 MΩ/KM·20℃ | |
| SPARK TEST | 500V | |
| DICLECTRIC STRENGTH | 500V/MIN | |
| AL MYLAR | COVERAGE | 100% |
| OVERLAP | 25% |
